PACIFIC

S-20 DISK

WALK-BEHIND AUTO SCRUBBER

This machine features specifications and attributes you would find in the premium price ranges, but at a mid-market price. The S-20 offers key performance features such as Batteryshield® – the first integrated automatic wet battery protection system, up to 3.5 hours of run time, on-board “1,2,3-step” visual operation guide, and optional Hydrolink® – single-point battery watering system.



Available in both Traction and Pad Assist configurations


SOLUTION CAPACITY: 11 gallons / 42 liters
CLEANING PATH WIDTH: 20 in / 510 mm
BRUSH/PAD REMOVAL: Automatic on/off
PAD DOWN PRESSURE: 60 & 90 lb / 27 & 41 kg
RUN TIME: Up to 3.5 hours

PACIFIC’S S-20 DISK IS PURPOSE BUILT ®
FOR SUSTAINABLE CLEANING

NO STRAINING

  • Automatic on/off brush system.
  • Elimates kneeling or back strain.

AVAILABLE WITH BATTERYSHIELD®
(Not available on Pad Assist models)

  • Eliminates premature disposal of lead-acid batteries.

BEST-IN-CLASS NOISE LEVELS

  • Noise levels at 63 DBA to allow for “anytime” cleaning.

AUTOMATED BATTERY PROTECTION SYSTEM

(not avaiable on Pad Assist models)
With returns on your investment approaching 700%, making a small investment in the BatteryShield® system for your auto scrubber is simply a smart choice.

Learn more about BATTERYSHIELD

HOW IT WORKS

  • Low water levels detected by a special sensor
  • Sensor sends a signal to the machine
  • A control panel LED is illuminated signaling the operator
  • The machine’s scrub brush motors are shut-down until batteries are watered
  • The operator performs the watering maintenance using HydroLink®, the fastest, safest and most foolproof watering system available.

ASK FOR BATTERYSHIELD®!

Tier 1 specs. Affordable price.

This machine may very well be the best value in auto scrubbers. The machine features specifications and
attributes you would find in the premium price ranges, but at a mid-market price.


 THE PACIFIC S-20 DISK IS THE PERFECT CHOICE FOR:

  •  Daily scrubbing & project work (deep scrub or strip jobs) of smaller facilities
  • Dedicated facility or multi-facility route cleaning programs
  • Small rooms, detail & edge cleaning in larger facilities
  • Grout and porous floor scrubbing
  • Entry-ways & lobbies
  • Check-out aisles
  • Spill cleanup & water recovery



PACIFIC

S-20 Disk Specifications


Print Specifications

Model Specifications: Pacific S-20 Disk (Pad Assist & Traction)

MODEL: S-20 (Disk) Pad Assist S-20 (Disk) Traction
Solution Delivery System:
Solution Capacity 11 gal / 42 l 11 gal / 42 l
Solution Control 0-.5 gpm / 0-1.9 lpm Variable, knob adjustment 0-.5 gpm / 0-1.9 lpm Variable, knob adjustment
Scrubbing System:
Cleaning Path Width 20 in / 510 mm 20 in / 510 mm
Pad / Brush Size (1) 20 in / 510 mm (1) 20 in / 510 mm
Productivity Theoretical Max (per hr) 23,800 ft2 / 2,211 m2 23,800 ft2 / 2,211 m2
Productivity Average Coverage Rate (per hr) 10,630 ft2 / 988 m2 10,630 ft2 / 988 m2
Brush Drive System:
Brush Motor HP .75 hp / 560 W .75 hp / 560 W
Brush RPM 230 rpm 230 rpm
Brush/Pad Pressure 60 & 90 lb / 27 & 41 kg 60 & 90 lb / 27 & 41 kg
Brush/Pad Attachment/Removal Automatic on/off
Recovery System:
Tank Accessibility Full clean out access
Tank Capacity 13 gal / 49 l (2 gal / 7.6 l demisting chamber) 13 gal / 49 l (2 gal / 7.6 l demisting chamber)
Vacuum Motor Power .51 hp / 380 W, 2-stage .51 hp / 380 W, 2-stage
Vacuum Motor Flow 68 cfm / 1.9 cmm 68 cfm / 1.9 cmm
Squeegee Width 30 in / 76 cm 30 in / 76 cm
Drive System:
Type Pad assist Traction
Motor Power N/A .25 hp / 187 W
Battery & Charging System:
System Voltage 24 V 24 V
Batteries 12 V (2 required)
Battery AH Rating 155 AH (wet) / 140 AH (MF) 155 AH (wet) / 140 AH (MF)
Run Time Up to 3 hours Up to 3.5 hours
Charger Type On-board On-board
Machine Specifications:
Length 50 in / 127 cm 50 in / 127 cm
Width without Squeegee 21 in / 53 cm 21 in / 53 cm
Height 43 in / 109 cm 43 in / 109 cm
Weight with Batteries 380 lb / 172 kg 400 lb / 181 kg
Sound Level at Operator's Ear 63 dBA 63 dBA
Construction Rotationally molded polyethylene tanks, powder coated steel frame
Warranty:
Rotationally Molded Tanks 10 years
Parts (excluding wear items) 3 years
Isolators N/A
Labor 1 year
Batteries 90 days replacement, 1 year prorated
*Productivity calculations utilize key factors from the ISSA 540 cleaning times handbook
Note: Specifications subject to change without notice
Toggle to View Specs

Model Specifications: Pacific S-20 Disk (Pad Assist & Traction)

MODEL: S-20 (Disk) Pad Assist S-20 (Disk) Traction
Solution Delivery System:
Solution Capacity 11 gal / 42 l 11 gal / 42 l
Solution Control 0-.5 gpm / 0-1.9 lpm Variable, knob adjustment 0-.5 gpm / 0-1.9 lpm Variable, knob adjustment
Scrubbing System:
Cleaning Path Width 20 in / 510 mm 20 in / 510 mm
Pad / Brush Size (1) 20 in / 510 mm (1) 20 in / 510 mm
Productivity Theoretical Max (per hr) 23,800 ft2 / 2,211 m2 23,800 ft2 / 2,211 m2
Productivity Average Coverage Rate (per hr) 10,630 ft2 / 988 m2 10,630 ft2 / 988 m2
Brush Drive System:
Brush Motor HP .75 hp / 560 W .75 hp / 560 W
Brush RPM 230 rpm 230 rpm
Brush/Pad Pressure 60 & 90 lb / 27 & 41 kg 60 & 90 lb / 27 & 41 kg
Brush/Pad Attachment/Removal Automatic on/off
Recovery System:
Tank Accessibility Full clean out access
Tank Capacity 13 gal / 49 l (2 gal / 7.6 l demisting chamber) 13 gal / 49 l (2 gal / 7.6 l demisting chamber)
Vacuum Motor Power .51 hp / 380 W, 2-stage .51 hp / 380 W, 2-stage
Vacuum Motor Flow 68 cfm / 1.9 cmm 68 cfm / 1.9 cmm
Squeegee Width 30 in / 76 cm 30 in / 76 cm
Drive System:
Type Pad assist Traction
Motor Power N/A .25 hp / 187 W
Battery & Charging System:
System Voltage 24 V 24 V
Batteries 12 V (2 required)
Battery AH Rating 155 AH (wet) / 140 AH (MF) 155 AH (wet) / 140 AH (MF)
Run Time Up to 3 hours Up to 3.5 hours
Charger Type On-board On-board
Machine Specifications:
Length 50 in / 127 cm 50 in / 127 cm
Width without Squeegee 21 in / 53 cm 21 in / 53 cm
Height 43 in / 109 cm 43 in / 109 cm
Weight with Batteries 380 lb / 172 kg 400 lb / 181 kg
Sound Level at Operator’s Ear 63 dBA 63 dBA
Construction Rotationally molded polyethylene tanks, powder
coated steel frame
Warranty:
Rotationally Molded Tanks 10 years
Parts (excluding wear items) 3 years
Isolators N/A
Labor 1 year
Batteries 90 days replacement, 1 year prorated

*Productivity calculations utilize key factors from the ISSA 540 cleaning times handbook
Note: Specifications subject to change without notice

PACIFIC

S-20 Disk References


20” DISK AUTO SCRUBBERS

TIER 1 SPECS. AFFORDABLE PRICE.

This machine may very well be the best value in auto scrubbers. The machine features specifications and attributes you would find in the premium price ranges, but at a mid-market price

Download Spec Sheet

PACIFIC S-20 DISK

WALL CHART

A quick-glance operational and maintenance chart for convenient wall display

Download Wall Chart

PACIFIC

S-20 Disk Service


PACIFIC S-20 DISK AUTOSCRUBBER

PARTS & OPERATING MANUAL

The Parts and Operating Manual contains important information about proper operation and care.

Key topics include:

  • Unpacking the machine
  • Drive System
  • Charging
  • Scrub Deck Set-up
  • Recovery System
  • Recommended Maintenance
  • Part Listings & Schematics
  • Warranty Information

Download Parts & Operating Manual

PACIFIC S-24XM AUTOSCRUBBER

WARRANTY POLICY

Pacific Floorcare auto scrubbers have been manufactured, tested and inspected in accordance with specific engineering requirements. Machines are warranted to be free from defects in workmanship and materials for the periods outlined below. The warranty extends to the original user/purchaser only when used, operated and maintained in accordance with Pacific Floorcare Operating and Maintenance instructions.

Download the S-20 Warranty Policy

Model 855416 Pacific S-20 Disk shown

Available Accessories

Item Number: Description:
850901 Brush, soft poly
850902 Brush, nylon
850903 Brush, abrasive grit)
855901 Pad driver (standard)
555926 Pad, 20" Maroon CFR , case of 10
555946 Pad, 20" Red scrub, case of 5
555956 Pad, 20" White polish, case of 5
555906 Pad, 20" Black strip , case of 5
555966 Pad, 20" Turf, case of 4

GENUINE SERVICE PARTS

PURPOSE BUILT™ TO PROVIDE MAX PERFORMANCE

Why buy a copy when you can get the original parts – the ones actually used in the machine’s original design work the best. Not only do you get maximum performance, but you also reduce hassle and downtime. Be sure to contact Pacific Floorcare or a local authorized distributor when you need authentic service parts.
