PACIFIC

FM-ME

MINI-EDGER FLOOR MACHINE

There are not many tools more flexible than the Pacific Floorcare® FM-ME floor machine and edger unit – plus, it delivers industrial performance. The mini-edger truly transfers many of your manual detail cleaning activities into an automated cleaning tool. Use the FM-ME on hard floors, carpets, baseboards, stair treads, elevator tracks and other hard to reach, tight spaces – you’ll run out of time, before you’ll run out of uses!


HD PERFORMANCE: Almost 20 lb of focused down pressure at 765 rpm
PAD SPEED RPM: 1,500 rpm
FLEXIBILITY: Attachments for baseboard, hard floor, stairs and carpet cleaning
EASE OF USE: Fit to your comfort with quick adjust handle




THE PACIFIC FM-ME MINI-EDGER IS PURPOSE BUILT ™ FOR:

  • Baseboard cleaning
  • Edges and corner cleaning
  • Carpets
  • Stairs & elevator tracks
  • Restrooms
  • Many tight spaces
The Pacific FM-ME Mini-Edger floor machine is made to automate many of the detail work jobs in your cleaning programs.



PACIFIC

FM-ME Mini-Edger Specifications




Print Specifications

Model Specifications: Pacific FM-ME Mini-Edger Floor Machine

Model number FM-ME
Part number 515451
Pad Drive System
Motor horsepower: .8 hp
Pad speed rpm: 765 rpm
Pad diameter: 6.5 in
Equipped with pad driver: Yes & Mal-GritTM brush and splash guard
Productivity (per hour)*: 20,000 ft2 (baseboards)
810 ft2 (floors)
Electrical System
Voltage: 115 V
Power consumption amps: 1.7 amp
Power cord length / type: 11 in pigtail, 18/3 SJO
Machine Specifications
Product length: 50 in
Product width: 6 in
Product height: 40 in (with brush)
Product weight (w/cord): 16 lb
Sound level (operator’s ear): 67 dBA
Construction: Epoxy-coated cast aluminum motor base
ABS switch housing, steel plated handle tube
Warranty
Motor: 1 year
All other components**: 1 year
*Productivity from the ISSA 540 cleaning times handbook
**Excluding wear items
Note: Specifications subject to change without notice
Toggle to View Specs

Model Specifications: Pacific FM-ME Mini-Edger Floor Machine

Model number FM-ME

Part number 515451

Pad Drive System
Motor horsepower: .8 hp
Pad speed rpm: 765 rpm
Pad diameter: 6.5 in
Equipped with pad driver: Yes & Mal-GritTM brush and splash guard
Productivity (per hour)*: 20,000 ft2 (baseboards)
810 ft2 (floors)
Electrical System
Voltage: 115 V
Power consumption amps: 1.7 amp
Power cord length / type: 11 in pigtail, 18/3 SJO
Machine Specifications
Product length: 50 in
Product width: 6 in
Product height: 40 in (with brush)
Product weight (w/cord): 16 lb
Sound level (operator’s ear): 67 dBA
Construction: Epoxy-coated cast aluminum motor base
ABS switch housing, steel plated handle tube
Warranty
Motor: 1 year
All other components**: 1 year

*Productivity from the ISSA 540 cleaning times handbook
**Excluding wear items
Note: Specifications subject to change without notice

PACIFIC

FM-ME Mini-Edger Reference & Service


Industrial-duty and flexibility for your tight-space, stair and baseboard cleaning needs

There are not many tools more flexible than the Pacific Floorcare™ FM-ME floor machine and mini-edger unit – plus, it delivers industrial performance. The mini-edger truly transfers many of your manual detail cleaning activities into an automated cleaning tool.

Download Spec Sheet

Pacific FM-ME

OPERATING MANUAL

The Operating Manual contains important information about proper operation and care.

Key topics include:

  • Machine Overview
  • Set-up
  • Pad / Brush Selection
  • Operation
  • Wiring Diagram
  • Specifications
  • Warranty Information

Download Operating Manual

Model Pacific FM-ME Mini-Edger shown

Available Accessories

Part Number: Description:
513650 Splash guard
510950 Brush, Mal-Grit
515950 Pad driver
510952 Brush, poly , 8 in flat
510954 Brush, nylon
510956 Brush, grout Mal-Grit
555900 Pad, 6.5" Black strip, case of 15
555910 Pad, 6.5" Brown strip, case of 15
555930 Pad, 6.5" Green scrub, case of 15
555940 Pad, 6.5" Red scrub, case of 15
555950 Pad, 6.5" White polish, case of 15
555960 Pad, 8" Turf, case of 4
511354 Carpet bonnets, yarn, case of 6

GENUINE SERVICE PARTS

PURPOSE BUILT™ TO PROVIDE MAX PERFORMANCE

Why buy a copy when you can get the original parts – the ones actually used in the machine’s original design work the best. Not only do you get maximum performance, but you also reduce hassle and downtime. Be sure to contact Pacific Floorcare or a local authorized distributor when you need authentic service parts.
